52
8. Outline of the Product
● Specifications
Model No.
NK-6
Proximal
Male Pyramid Adapter
Connection
Selective Lock
–
Total Length
A ref.
measurement
B ref.
measurement
Weight
920g
Max. Knee
Flexion Angle
Material
125kg (100kg For Hip Prosthesis & High Active User)
Max. Body
Weight
Mobility Grade
Active ~ High Active (K-Level 3+4, Mobility Class 3+4)
* These specifications are subject to changes without prior notice.
Fig.23 Installation Height
● Lifetime:
6 years
● Features
Smooth walking
The product is named "Symphony" because the
knee smoothly harmonizes between the stance
phase and swing phase control. The p-MRS
system controls shifting from the stance phase to
the swing phase seamlessly.
High stability of stance and Stance-Flexion
function
The 6-bar linkage using the p-MRS system
identifies floor reaction force positions and
controls the knee stability. The Stance-Flexion
feature will reduce an impact at the heel strike and
also reduce bobbing of center-of-mass.
Locking of knee by selective lock (optional)
The user can lock the knee by himself/herself.
Whenever the user needs stability, for example,
while working at standing posture, walking on
snowy road, in strong winds or on irregular
ground, he/she
completely prevent knee buckling.
NK-6+L
NK-6SH
O
–
197mm
14mm
156mm
970g
960g
170°
Titanium & Aluminum
Compliance with ISO 10328 P6(A-125kg)
can
lock
his/her
EN – 24
NK-
6SH+L
Screw Head
O
191mm
14.5mm
156mm
1010g
knee
to
P.26
