6.11
Setting the timer
The timer can be set to start and stop the unit at a pre-pro-
grammed time. In a first step these start and stop times must be
set.
1.
Press the SET TIME button twice until the upper right side
of the clock displays ON and the hour digits are flashing.
2.
Press the
/
button to set the hour when you want the
unit to switch on.
3.
Press the HOUR/MIN button, and then press the
ton to set the minutes.
4.
Press the SET TIME button again until the lower right side
of the clock displays OFF and the hour digits are flashing.
5.
Press the
/
button to set the hour when you want the
unit to switch off.
6.
Press the HOUR/MIN button, and then press the
ton to set the minutes.
7.
To end the setting mode press the SET TIME button again.
The clock time is shown. Alternatively, 10 seconds until the
digits stop flashing.
NOTE
You have now set the timer ON and OFF times, but
these must be activated separately. See chapter 6.12,
"Activating the timer" on page 15.
Fig. 44 Setting the timer
6.12
Activating the timer
Before activating the timer, select the operation mode, the set
temperature, and the desired fan level.
After the start and stop times are set (see chapter 6.11, "Setting
the timer" on page 15) one of the three different TIMER
modes can be activated:
l TIMER ON mode
In this mode the unit will switch on at the desired ON time
and keep on running.
l TIMER OFF mode
In this mode the unit will stop running at the desired OFF
time and will stay off.
9045225A_OI-II_Cool Top Trail 20G-24G ML
l TIMER ON / OFF mode
In this mode the unit will start to run at the ON time and
stop running at the OFF time. This pattern will be repeated
every day.
Fig. 45 TIMER Modes
/
but-
1.
Press the TIMER button repeatedly until either the ON or
OFF or both symbols are flashing depending on which timer
mode is preferred.
2.
To confirm the selection wait 10 seconds until the symbol
stops flashing and is shown permanently. The clock time is
now displayed again.
/
but-
Fig. 46 Activating the timer
NOTE
If the clock is displayed without an ON / OFF icon, then
you have not activated the timer.
6.13
Setting the sleep function
The sleep function automatically modifies the target temperat-
ure to provide a comfortable sleeping temperature. This also
helps to reduce compressor run time, energy consumption and
noise levels.
1.
Press the SLEEP button to activate the sleep function.
– The
icon is displayed in the display of the remote con-
trol to indicate that the sleep function is activated.
– In COOL mode the set temperature will automatically in-
crease in two steps and it will have increased by 2 °C
after two hours.
– In HEAT mode the set temperature will automatically de-
crease in three steps and it will have decreased by 3 °C
after two hours.
– The sleep function is only available in COOL or HEAT
mode.
2.
Press the SLEEP button again to deactivate the sleep func-
tion.
Fig. 47 Setting the sleep function
6.14
Changing the unit of temperature
Press the °C/°F button to select which temperature unit you
want to be displayed: Celsius or Fahrenheit.
l You can do this in any mode.
l The display on the air distributor follows the selection made
on the remote control.
Operating Instructions | 6
15 / 146
