3.4.1 Sanifos® 110 , Sanifos® 280 and Sanifos® 610 (single-pump model)
Sanifos® 110
INLET
Ø ext. 40/50
INLET
Ø ext. 100/110/125
Sanifos® 280
DISCHARGE
DN50 o DN40
(according to the model)
3.4.2 Sanifos
610 (2-pump model) and Sanifos
®
Sanifos® 610
VENTILATION
Øext 75
DISCHARGE
DN 40 (Øext 50) or DN 50 (Øext 63)
depending on the model
Sanifos® 1300
VENTILATION
Øext. 100
DISCHARGE
Øext. 63
3.5 TECHNICAL SPECIFICATIONS
Volume of the tank
Material of the tank
polyethylene
FEA without extension
FEA with extension
24
VENTILATION
Ø ext. 75
DISCHARGE
INLET
INLET
Ø ext. 100/110/125
VENTILATION
INLET
to be drilled
DN50 or DN100
(opening to be drilled)
DN 50 or DN 100
VENTILATION
VENTILATION
VENTILATION Øext 100
INLET
to be drilled
DN50, DN100 or DN160
Sanifos® 110
Sanifos® 280
110 litres
280 litres
polyethylene
182 mm
250-600 mm
N/A
550-900 mm
Operating mode:
Effluents enter the pumping station through the horizon-
tal inlet openings.
They accumulate in a gas-tight, smell-proof and waterti-
ght plastic tank.
As soon as a certain fill level is detected by the float swit-
ch, the pump starts up automatically.
G2"
Effluents are automatically raised up to flow into the drain
Ø ext. 40/50
pipe.
As soon as the effluent level reaches a minimum effluent
level in the tank, detected by the float switch, the pump
switches off automatically.
Ø ext. 75
1300
®
Operating mode:
Effluents enter the pumping station through the hori-
zontal inlet openings. They accumulate in a gas-tight,
smell-proof and watertight plastic tank. When the ef-
fluent enters the tank, the low float rises and then the
high float rises to reach the pump's activation level.
INLET
The pump starts up and the effluents are lifted automa-
tically to flow into the drain pipe.
As soon as the effluent level reaches a minimum effluent
level in the tank, detected by the low float switch, the
pump switches off automatically.
Sanifos® 610 and Sanifos® 1300 contain 2 pumps that
operate alternately. In case of malfunction, the alarm is
triggered by the alarm float and the 2 motors operate
simultaneously. If one of the 2 pumps is defective, the
Øext. 100
other one takes over.
Øext. 100
Sanifos® 610
610 litres
polyethylene
325-580 mm
725-980 mm
Sanifos® 1300
1300 litres
polyethylene
560-1460 mm
960-1860 mm
