6.0 Possible Problems
Wheelchair pulls to one side
•
Check tyre pressure
•
Check to make sure wheel turns easily
(bearings, axle)
•
Check angle of casters
•
Check to make sure both castors are making proper contact with the ground
Castors begin to wobble
•
Check angle of casters
•
Check to make sure all bolts are secure; tighten if necessary (see the page on torque)
•
Check to make sure both castors are making proper contact with the ground
Wheelchair / Cross-tube assembly does not snap into position in the seat saddle
•
Chair is still new, i.e. the seat or backrest upholstery is still very stiff. This will improve with continued use
Wheelchair is difficult to fold up
•
Adjustable backrest up holstery is too stiff; loosen it accordingly
Wheelchair squeaks and rattles
•
Check to make sure all bolts are secure; tighten if necessary (see the page on torque)
•
Apply small amount of lubrication to spots where movable parts come in contact with one another
Wheelchair begins to wobble.
•
Check angle at which casters are set
•
Check tyre pressure
•
Check to see if rear wheels are adjusted differentl
7.0 Technical Specifications
Max. user weight:
Seat width:
Seat depth:
Front seat height:
Rear seat height:
Backrest height:
Backrest angle:
Total width:
Overall length:
Total height:
Turning radius:
Maximum slope for the use of the wheel locks:
Rear wheel:
Castor:
Frame version:
Weight of wheelchair:
Disassembled weight:
Mass of the heaviest part:
Detachable parts:
Colours:
Crash Test:
Max. User weight 85 kg
The wheelchair conforms to the following standards:
1. Requirements and test methods for static, impact and fatigue strengths (ISO 7176-8)
2. Flammability resistance of upholstered parts in accordance with ISO 7176-16.
Rev.P
English
85 kg
220 – 400 mm (+/-20 mm)
240 – 400 mm (+/-40 mm)
370 – 500 mm
320 – 470 mm
225 – 425 mm
-3° -15°
700 mm (310 mm folded)
930 mm
920 mm
600 mm
7°
20"22"/24"
4"/5"/6"
Standard & Abduction
from 8.5 kg
from 6.4 kg
2.1 kg
Rear wheels (only for transportation)
32
Yes
.
23
Youngster 3
