3.0 General Description Sedeo Pro Advanced
This wheelchair is equipped with Sedeo Pro Advanced seating system.
The Sedeo Pro Advanced seating system provides good support
for the head, torso, arms and legs. Optimal body support ensures
maximum independence for the wheelchair user.
The wheelchair must be adjusted by a qualified specialist. Incorrect
settings may have negative consequences for the seating posture.
Due to its modular design, simplicity and wide range of adjustments,
the Quickie Q700-UP series is a perfect choice for easy service,
refurbishment and recycle requirements.
To fulfil individual preferences, needs or circumstances, the Q700-UP
series is available in the following configurations:
• Midwheeldrive (MWD): Q700-UP M
• Frontwheeldrive (FWD): Q700-UP F
To have optimum seating support and individual adjustments the
Q700-UP series is available in combination with the
• Sedeo Pro Advanced UP seating system.
8
Fig. 3.1
8
Main components:
1. Headrest
2. Joystick
3. Armrest
4. Seat cushion
5. Knee Fixation (if fitted)
6. Leg rest
7. Footrest
8. Back upholstery
9. Power Seating/Stand-up Module (not
shown)
Sedeo Pro Advanced/Advanced UP | Rev.D | English
1
2
3
5
4
6
7
