CHAPTER 4: OPERATION
To control a receiver, the transmitter must be registered and logged in to the receiver. If another
transmitter is already logged in to the receiver, it must be logged out before a different transmitter can be
logged in. If no transmitter is logged in to a receiver, any registered transmitter will automatically log in
when sending radio signals to the receiver. The transmitter will remain logged in until it is manually
logged out.
NOTES! More than one transmitter can be registered in the receiver, but only one transmitter can be
logged in at a time.
REGISTER THE TRANSMITTER IN THE RECEIVER
Do not perform this action when the receiver is in a session with another
transmitter. The radio communication may be interrupted or broken.
NOTE! Only transmitters that are intended for use should be registered in the receivers.
NOTE! To establish a radio link between the transmitter and the receiver, both units must be set to the
same radio mode.
1. Make sure that the stop button is pressed.
2. Twist and pull out the stop button.
The top LED lights (green when the battery capacity is good, red when the battery capacity is
poor), LEDs 3 and 4 flash (red).
3. Press buttons 7 and 8 at the same time for at least 1 second.
LEDs 3 and 4 light (red).
4. Release buttons 7 and 8.
LEDs 3 and 4 go out. The top LED flashes (green).
5. Press the receiver Function button.
The function LED lights (red).
6. Press the receiver Select button.
All relay LEDs light (red).
7. Press buttons 1 and 2. Keep pressed.
All relay LEDs light (red). All relay LEDs flash 2 times (red).
8. Release buttons 1 and 2.
All relay LEDs flash 1 time (red).
The transmitter is registered.
If no transmitter is found within approximately 10 seconds, the receiver exits to normal operation.
- 10 -
