3.0 Intended use of the wheelchair
General description
The Q500 range is an ultimate modular power wheelchair. A
distinctive feature is the suspension system that allows you to have a
perfect driving experience indoors as well as outdoors.
Due to its modular design, simplicity and wide range of adjustments,
the Quickie Q500 series is a perfect choice for easy service,
refurbishment and recycle requirements.
The Q500 series fulfils individual preferences, needs or circumstances
and is available in the following configurations:
• Midwheeldrive (MWD): Q500 M
• Frontwheeldrive (FWD): Q500 F
• Rearwheeldrive (RWD): Q500 R
To have optimum seating support and individual adjustments the
Q500 series is available in combination with
• Sedeo Lite seating system (refer to seating manual &)
• Sedeo Pro seating system (refer to seating manual &)
3.1 Area of application: The user
Power wheelchairs are exclusively for a user who is unable to walk or
has limited mobility, for their own personal use indoors and outdoors.
Driving a powered wheelchair requires cognitive, physical and visual
skills. The user must be able to estimate and correct the results of
actions when operating the wheelchair.
The wheelchair cannot transport more than 1 person at a time. The
maximum weight limit (includes both the user and any weight of
accessories fitted to the wheelchair) is marked on the serial number
label, which is affixed to the chassis of the chair (Fig. 2.9).
For restrictions on user weight limit refer to seating manual &.
The user must be informed of the contents of this user manual before
driving the wheelchair. In addition, the user of the wheelchair must
be given thorough instruction by a qualified specialist before he or
she participates in traffic. The first sessions in the wheelchair should
be practiced under supervision of a trainer/advisor.
The variety of fitting variants as well as the modular design mean
that this wheelchair can be used by those who cannot walk or have
limited mobility e.g. because of:
• Paralysis
• Loss of extremity (leg amputation)
• Extremity defect deformity
• Joint contractures/joint injuries
• Strokes and brain injuries
• Neurological disabilities (e.g. MS, Parkinson...)
• Illnesses such as heart and circulation deficiencies, disturbance of
equilibrium or cachexia as well as for elderly people who still have
the strength in the upper body.
• Persons who are mentally and physically able to control an input
device to operate the chair and its functions in a safe way.
• The maximum user weight shall not exceed 160 kg with Sedeo Pro,
136 kg with Sedeo Lite.
Basic Components (Fig.3.1).
Headrest
1.
Joystick
2.
Arm Rest
3.
Side Cushion
4.
5.
Seat Cushion
Leg Rest
6.
8
7.
Front Castor
Drive Wheel
8.
Rear Castor
9.
10. Motors
11. Battery Box
12. Back Upholstery
Fig. 3.1
12
11
10
9
8
12
11
10
9
8
12
11
10
8
1
2
3
5
6
7
1
2
3
4
5
6
1
2
3
4
5
6
7
Q500 M/F/R Rev.B
