Sieve in the water shortage safeguard
41
Fine filter (water)
42
Float container
43
Control panel
Illustration C
0/OFF = off
Power switch
1
Operating mode: Cold water operation
2
Operating mode: Hot water operation (e = Eco
3
mode, hot water max. 60°C)
Direction of rotation indicator light (3-phase devices
4
only)
Standby mode indicator light
5
Fuel indicator light
6
Service indicator light
7
Detergent indicator light
8
System care indicator light
9
Colour coding
● Control elements for the cleaning process are yel-
low.
● Control elements for maintenance and servicing are
light grey.
Symbols on the device
Do not aim the high-pressure jet may at
persons, animals, live electrical equip-
ment or the device itself.
Protect the device against frost.
Danger of injury from electrical voltage.
Only qualified electricians or authorised
and qualified technical specialists are
permitted to work on the electrical sys-
tems.
Health risk from poisonous exhaust gases.
Never inhale the exhaust gases.
Risk of burns from hot surfaces.
Intended use
Only use the device for cleaning, e.g. machines, vehi-
cles, buildings, tools, façades, terraces and garden
equipment.
DANGER
Use at petrol stations or other hazard zones
Risk of injury
Adhere to the respective safety regulations.
Note
Do not allow waste water containing mineral oil to pen-
etrate soil, waterways or the sewage system. Only wash
the motor or the undercarriage in suitable places with an
oil separator.
Water supply limit values
ATTENTION
Dirty water
Premature wear and tear or deposits in the device
Supply the device using only clean water, or recycled
water that does not exceed the specified limit values.
The following limit values apply to the water supply:
● pH value: 6.5-9.5
● Electrical conductivity: Conductivity of fresh water
+ 1200 µS/cm, maximum conductivity 2000 µS/cm
● Settleable particles (sample volume 1 l, settling time
30 minutes): < 0.5 mg/l
● Filterable particles: < 50 mg/l, no abrasive sub-
stances
● Hydrocarbons: < 20 mg/l
● Chloride: < 300 mg/l
● Sulphate: < 240 mg/l
● Calcium: < 200 mg/l
● Total hardness: < 28 °dH, < 50° TH, < 500 ppm
(mg CaCO
/l)
3
● Iron: < 0.5 mg/l
● Manganese: < 0.05 mg/l
● Copper: < 2 mg/l
● Active chloride: < 0.3 mg/l
● Free of unpleasant odours
Safety instructions
The following safety instructions apply to the device:
● Observe the respectively applicable national regula-
tions for liquid jet cleaners.
● Observe the respectively applicable national acci-
dent prevention regulations. Liquid jet cleaners must
be tested regularly and the results of the test record-
ed in writing.
● Note that the heating system in the device is classi-
fied as a furnace. Furnaces must be inspected reg-
ularly according to the applicable national
regulations.
● No modifications may be made to the device or ac-
cessories.
Safety devices
Safety devices protect the user and may not be disabled
or functionally circumvented.
Overflow valve with 2 pressure switches
● When the water volume at the pump head is re-
duced, the overflow valve opens and some of the
water flows back to the pump suction side.
● If the high-pressure gun is closed so that all the wa-
ter flows back to the pump suction side, the pres-
sure switch on the overflow valve switches off the
pump.
● If the high-pressure gun is opened again, the pres-
sure switch on the cylinder head switches the pump
on again.
● The overflow valve is set and sealed at the factory.
The adjustment is performed only by customer ser-
vice.
● The safety valve opens if the overflow valve or pres-
sure switch is faulty.
● The safety valve is adjusted and sealed at the facto-
ry. The adjustment is performed only by customer
service.
English
Safety valve
17
