46. Threaded bolt pivot point
47. Threaded bolt slotted hole
48. Sleeve
49. Locking button
50. Wing handle
51. Washer
52. Nut, self-locking
53. Spring washer
54. Grub screw in swing arm
55. Spindle
56. Thicknessing safety switch
57. Recess for thicknessing safety switch
58. Power cable
59. Cable holder
60. Hex key – 3 mm
61. Hex key – 5 mm
62. Hex key – 6 mm
63. Open-ended spanner 8/10 mm
2.2 Items supplied
Please check that the article is complete as
specifi ed in the scope of delivery. If parts are
missing, please contact our service center or the
sales outlet where you made your purchase at
the latest within 5 working days after purchasing
the product and upon presentation of a valid bill
of purchase. Also, refer to the warranty table in
the service information at the end of the operating
instructions.
•
Open the packaging and take out the equip-
ment with care.
•
Remove the packaging material and any
packaging and/or transportation braces (if
available).
•
Check to see if all items are supplied.
•
Inspect the equipment and accessories for
transport damage.
•
If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suff ocating!
•
Surfacing and thicknessing planing machine
•
Push block (2x)
•
Push stick
•
Hand crank
•
Chip extractor
•
Parallel stop
•
Extraction adapter Ø 100 mm
•
Rubber foot (4x)
•
Planing knife cover
Anl_TC-SP_204-1_SPK13.indb 23
Anl_TC-SP_204-1_SPK13.indb 23
GB
•
Setting gauge for planing knives (2x)
•
Washer for rubber feet (4x)
•
Socket head screw for rubber feet (4x)
•
Cover plate for knife
•
Parallel stop socket head screw (2x)
•
Sleeve
•
Locking button
•
Washer (2x)
•
Nut, self-locking
•
Spring washer
•
Hex key – 3 mm
•
Hex key – 5 mm
•
Hex key – 6 mm
•
Open-ended spanner 8/10 mm
•
Original operating instructions
•
Safety instructions
3. Proper use
The surfacing and thicknessing plane is designed
for the surfacing and thicknessing of all types of
peeled pieces of square, rectangular or chamfe-
red converted timber.
The machine is allowed to be used only for
its prescribed purpose.
Even when the machine is used as prescribed
it is still impossible to eliminate certain residual
risk factors. There is a risk of the following injuries
in connection with the required operation of the
machine.
•
Fingers or hands coming into contact with the
knife shaft in areas which are out of view.
•
Workpieces might kick back if the machine is
used incorrectly.
•
Damage to hearing and eye injuries plus
injuries to fingers and hands if the required
protective equipment is not used.
•
Harmful emissions when used in enclosed
spaces without a suitable extractor system.
The machine is allowed to be used only for its
prescribed purpose. Any other use is deemed to
be a case of misuse. The user/operator and not
the manufacturer will be liable for any damage or
injuries of any kind resulting from such misuse.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
- 23 -
