4.0 Battery
Start Up:
Information on the operating modes:
Essentially, the battery has two operating modes.
It is either in "Active mode" or in "Off mode".
In active mode the battery consumes at least 50 mA per
hour (consumption of the battery's own electronics and
display).
Inserting the battery:
(Fig.4.1).
• Place the battery [1] into the battery slot [6] mounted
on the add-on bike.
• Lock the battery [1] by carefully turning the key [2]
clockwise until it stops.
• The battery can no longer be removed from the
battery slot.
• Remove the key [2] from the battery [1].
Switching on the battery:
The battery is switched on by operating the on/off rocker
switch, (Fig.4.2).
Your add-on bike is now ready for use.
If the battery cannot be switched on, the cell voltage may
be too low. In this case connect the charger, (see next
page) and then press the on/off button [4]. The battery
will be charged for a minute.
Battery capacity indicator:
You can check the battery capacity at any time using the
LED display. Press the button, (A), briefly to display the
charge status, (Fig.4.3).
Detaching the battery:
Switching off the battery:
The battery is switched on by operating the on/off rocker
switch, (Fig.4.2).
Removing the battery:
Reverse the insertion procedure, (Fig.4.1).
Insert the key [2] in the lock on the battery [1].
Carefully turn the key [2] anticlockwise until it stops. The
lock is now released.
Pull the battery [1] downwards out of the slot and then
remove it completely.
Store the battery in a safe clean place.
Attitude Power Rev.H
Fig.4.1
2
Fig.4.2
Fig.4.3
Füllstand Batterie/Battery Level
100%
80%
50%
A
20%
37
