Button 2 of the Vocatex switches between HDMI 1 and HDMI 2, or HDMI 1 and HDMI 3.
To use the button on the front panel, the Vocatex needs to be connected on HDMI 1, your computer needs
to be connected on HDMI 2 or 3 of the screen. Connect with a HDMI-HDMI, HDMI-DVI or HDMI-
DisplayPort cable.
The computer connection of the Vocatex has 2 possibilities:
Full screen (most common)
By pressing the pc button on the Vocatex, the screen switches to your computer. The full computer image
is displayed on your screen. Recommended resolution: 1360x768 or 1280x720.
Split Screen
(in combination with ZoomText 10 and higher or SuperNova 15.03 and higher) – only Windows OS
With the split screen possibility you can use a part of the screen to display the Vocatex image and another
part to display your computer. The video image can simply be put on top, bottom, left or right while having
you computer image on the same screen. When working in split screen mode you will have full access to
your computer.
The video image is send with a USB second cable to your computer. Use the button 2 to switch to full
screen. Open ZoomText or SuperNova and start the camera function. The video image is displayed.
Specifications Computer
•
Unused USB port (USB 3.0 or 2.0)
•
Windows 10, 8.1, 8, 7 – 32/64 bit;
•
ZoomText 10 and higher or SuperNova 15.03 and higher.
Installation
•
Connect the Vocatex to the computer via the USB cable (USB 3.0 preferred);
•
Configure the Vocatex as camera under ZoomText or SuperNova;
•
Start ZoomText or SuperNova webcam.
PROGRAMMABLE BUTTONS
The Vocatex has programmable buttons. Buttons 2, 3, 4 and 6 can have different functions and
possibilities. These functions can be activated by your dealer.
Button 2:
•
Switch between magnifier and computer (default)
•
Reset
Button 3 (press shortly to navigate between the different possibilities)
•
Brightness/background, Reading bar, Ticker (default)
•
Lighting, Reading line, Reading bar with ticker
Button 4: Different colour combinations
•
Black/White, White/Black, Black/Yellow, Yellow/Black, Black/Green, Green/Black (default)
•
Black/Red, Red/Black, Black/Blue, Blure/Black, Black/Cyan, Cyan/Black, Black/Magenta, Magenta/Black,
Black/Orange, Orange/Black, Black/Gray, Gray/Black, Blue/Yellow, Yellow/Blue, Blue/White, White/Blue,
Red/White, White/Red, Orange/White, White/Orange, Green/White, White/Green
KOBA Vision Vocatex 4
36
