7. HOB - HINTS AND TIPS
WARNING!
Refer to Safety chapters.
7.1 Cookware
For induction cooking zones a strong
electro-magnetic field creates the heat in
the cookware very quickly.
Use the induction cooking zones with
suitable cookware.
Cookware material
• correct: cast iron, steel, enamelled steel,
stainless steel, multi-layer bottom (with a
correct marking from a manufacturer).
• not correct: aluminium, copper, brass,
glass, ceramic, porcelain.
Cookware is suitable for an induction hob
if:
• water boils very quickly on a zone set to
the highest heat setting.
• a magnet pulls on to the bottom of the
cookware.
The bottom of the cookware must be as
thick and flat as possible.
Ensure pan bases are clean and dry
before placing on the hob surface.
Cookware dimensions
Induction cooking zones adapt automatically
to the dimension of the bottom of the
cookware. For correct cookware dimensions
refer to "Cooking zones specification" table.
Place the cookware in the center of of the
selected cooking zone.
For optimal heat transfer use cookware with
bottom diameter similar to the maximum size
of the cooking zone specified in Cookware
diameter.
7.2 Cooking zones specification
Cooking
Cookware diameter
zone
(mm)
Left rear
125 - 140
Right rear
145 - 180
Right front
145 - 180
Left front
180 - 210
7.3 Noises during operation
The noises are normal and do not
indicate any malfunction. Cookware
noises may vary depending on the
cookware material and the power level.
Cookware-related noises:
• cracking noise: cookware is made of
different materials (a sandwich
construction).
• whistling sound: you use a cooking zone
with a high power level and the cookware
is made of different materials (a sandwich
construction).
• humming: you use a high power level.
Hob-related noises:
• clicking: electric switching occurs.
• hissing, buzzing: the fan operates.
• rhythmic sound: cookware is detected.
7.4 Öko Timer Eco timer
To save energy, the heater of the cooking
zone deactivates before the count down timer
sounds. The difference in the operation time
depends on the heat setting level and the
length of the cooking operation.
7.5 Simplified cooking guide
The correlation between the heat setting of a
zone and its consumption of power is not
linear. When you increase the heat setting, it
is not proportional to the increase of the
consumption of power. It means that a
Power (W)
1400/2500
1800/2800
1800/2800
2300/3600
ENGLISH
49
