Hold the file at right angles (90°) to the guide bar when
sharpening.
Using the round file and the correct sharpeni
correct breast angle β will result.
The planing tooth lengthes (a) must be equal. Unequal
lengthes may lead to erratic chain run or chain breaking.
Once all sharpening angles are filed your saw chain is
sharp, but it will possibly not cut. There must be always
a depth gaug
e distance (T = distance between depth
gauge and cutting edge).
Use a flat file to file the depth gauge distance.
Be sure to chamfer the leading edge of your depth
limiter with a file. The original shape of the cutting link
must be preserved.
Only remove a little amount of material when
sharpening.
You can also sharpen your saw chain yourself by using our
electric shar
pener KSG 220 (article-no.: 302360).
Cleaning of guide bar
/
Check and clean the oil outlets (A) of the guide bar and the
guiding groove (B) on a regular basis.
Remove any burr using a flat file.
Turn round the guide b
sharpening to avoid single
Immediately replace a damaged guide bar.
Chain wheel
The demand of the chain wheel is particularly great. Check
reg
ularly the teeth of the chain wheel for wear
Clean the chain wheel (18) and the guide bar fixing
device using a brush.
A worn or d
amaged chain wheel reduces the durability
of the saw
chain and should therefore immediately be
exchanged by the customer service.
Cleaning the air filter
Clean the air filter from dust and dirt on a regular basis to
prevent
sta
rting problems,
-
loss of output,
-
too high fuel consumption.
-
C
lean the air filter every 8 op
dusty environments.
1. Open the air filter cover (21).
2. Remove the a
ir filter (22).
3. Cover the intake opening
from coming into the carburettor.
4. Pull apart the both parts of the air filter.
All manuals and user guides at all-guides.com
ng angle the
ar after each chain exchange /
-side wearing.
or damages.
erating hours, or more frequently in
with a clean cloth to prevent dirt
5.
Wash the air filter in a luke warm soapy solution.
Do not puff/blow out dirt particles, otherwise there is a
risk of eye injury.
6. Allow the air filter to dry well and reinsert it.
Damaged air filters must be
delay.
Checking / Replacing the fuel filter
The
chain saw is equipped with a fuel filter. Check it regularly
a
nd clean
or repla
ce it if required.
For this open the tank cap (9) and pull out the fuel filter (10).
If the filter is only slightly contaminated, carefu
oil li
ne
and
clean it using petroleum ether.
If it shows a great extent of contamination, replace the
fuel filter.
Checking / Replacing the spark plug
- Do not touch the spark plug or the spark plug
connector while the engine is running. High voltage!
- Risk of burning on the hot engine.
- Wear protective gloves.
Check the spark plug and the spark gap on a reg
For this
proceed as follows:
Op en the air filter cover (21).
Pull the spark plug connector (23) from the spark plug
(
24). Remove the spark plu
(36).
The spark gap must be 0.6 to 0.7 mm.
Clean the spark plug when it is contaminated.
Install the spark plug in revers
Do not overtighten the spark plug.
Replace
the spark plug:
ev
ery 100 hours or once in a year (which
-
fi
rs
t)
wh
en the insulating body is damaged,
-
when the electrodes show excessive erosion,
-
when the electrodes show excessive dirt or oil.
-
Use the following spark plug type:
Checking the ignition spark
1. Remove the spark plug (24).
2. Firmly connect the spark plug connector (23).
3. Use an insulated pair of tongs to press the spark plug
against the engine body (away from the spark plug hole).
4. Put the ON/OFF switch to the po
5. Pull the cranking rope.
If there is no spark visible between the el
spark plug may be defective.
replaced without
lly pull it from the
ular basis.
g using the supplied wrench
e order.
ever case comes
NGK-BPMR7A
BOSCH WSR6F
ORE
GON OPR15Y
CHAMPION
RCJ7Y
sition
.
ectrodes, the
