6.7. Functions of the display
Unit for the
Lights on/off
Speedometer,
Average speed,
Maximum Speed,
Trip time, Trip
distance,Total
kilometers
Drive level
Battery level:
(100/80/60/40/20%)
Switching on and off
Selection of the drive level; Lights on/off
Selection of the drive level
• After the pulling device is switched on by pressing the
"On/Off" button for 2 seconds (also see "Switching on
and off") the display shows the current speed in the
main screen and the total kilometres in the additional
display. In addition, the selected drive level (after
switching on, drive level 1 is pre-selected) as well as
the current battery capacity is displayed.
6.7.1 Lights:
The lights can be switched on or off by pressing the "+"
button for 2 seconds. This is displayed by the relevant
symbol on the display (upper left corner).
6.7.2 Battery capacity:
This is displayed in 20% steps. As soon as the battery
display starts to flash, the battery must be charged
immediately.
English | Rev.C
6.7.3 Display mode:
By pressing the "On/Off" button you can now select
different display modes:
Main display
depending on the
Speedometer
display mode
(Standard Speed)
Power consumption /
error codes
1. Display mode: "SPEED" - Speed
2. Display mode: "AVG SPEED" - Average speed
3. Display mode: "SPEED MAX" - Maximum speed
driven
4. Display mode: "ODO" - Odometer, total distance
driven
5. Display mode: "TRIP" – Total distance driven, since
last trip clear (see section deleting the trip meter)
6. Display mode: "TRIP TIME"- Total drive time since
last trip clear (see section deleting the trip meter)
• Only carry out setting work when the device is
stationary and never when driving.
19
Average speed
Trip time
Trip distance
DANGER!
Maximum speed
Total kilometers
Empulse StreetJet
