6.3. Selecting the direction of travel
• The direction control switch on
the handlebar allows you to
select the direction of travel.
When the switch is pushed
forwards in the direction of
travel, the pulling device moves
forwards when the throttle is
activated.
• In order to change the direction of travel, the pulling
device must be brought to a standstill. Then the
direction control switch must be moved to the
backwards position (travel direction to the back).
Activating the throttle will move the pulling device
backwards.
DANGER!
• The direction of travel can only be changed when the
device is stationary. Operating the direction control
switch when driving only has an effect once the device
has come to a standstill.
• Before setting off each time, check the position of the
direction control switch in order to avoid unintentionally
moving backwards (risk of injury).
• When driving backwards take note of your environment
in order to avoid collisions.
• Please note that the steering behaves differently when
going backwards compared with going forwards. Abrupt
steering movements can lead to a fall (risk of injury).
English | Rev.C
6.4. Controlling the speed (throttle)
• Using the throttle (A) you can control the speed with the
thumb of your right hand.
• By applying greater pressure, the speed increases, by
reducing the pressure, the speed will drop.
• When you let go of the throttle, the speed will drop, the
pulling device will roll to a standstill.
Quad controls
Quad control throttle is operated by pulling the lever (B) .
DANGER!
• Always adapt your speed to your environment in order
to avoid collisions (risk of injury).
• Familiarise yourself with the way your combined unit
handles cornering before you drive at higher speeds
(risk of injury).
• Before activating the throttle always check that the
direction control switch is set to the required direction of
travel.
• Always switch the pulling device off when docking and
de-docking as well as when it is not being used in order
to prevent accidental activation of the throttle.
NOTE:
• Driving at full throttle for long periods of time can mean
that the motor is subject to extreme thermal load. In
order to avoid overheating, the power will be restricted
until the motor reaches a normal operating temperature
again.
17
B
Empulse StreetJet
