Montagehandleiding
Tabel 11.4: Motoradapterplaat AM voor lineaire tafels HT-S
Lineaire as
Fabrikant
Motoren
HT100S
HIWIN
EM1-C-M-10-2
EM1-C-M-20-2, EM1-C-M-40-2
B&R
8LSA24, 8LSA25
8LSA33, 8LSA34
Beckhoff
AM8022D, AM8022E, AM8023E, AM8023F
AM8031D, AM8031F, AM8531D, AM8531F
Bosch
MSK030B, MSK030C
MSK040B, MSK040C
Lenze
MCS06F41, MCS06F60, MCS06I41, MCS06I60
Schneider
BSH0551, BSH0552
BSH0701, BSH0702, BMH0701, BMH0702
SEW
CMP40S, CMP40M
CMP50S
Siemens
1FK7022
1FK7032, 1FK7034
HT150S
HIWIN
EM1-C-M-20-2, EM1-C-M-40-2
EM1-C-M-75-2
B&R
8LSA33, 8LSA34, 8LSA35
Beckhoff
AM8022D, AM8022E, AM8023E, AM8023F
AM8031D, AM8031F, AM8531D, AM8531F
AM8041D, AM8041E, AM8041H, AM8541D, AM8541E, AM8541H
Bosch
MSK040B, MSK040C
MSK050B
Lenze
MCS06F41, MCS06F60, MCS06I41, MCS06I60
MCS09D41, MCS09D60
Schneider
BSH0701, BSH0702, BMH0701, BMH0702
BSH0703, BMH0703
BSH1001, BMH1001
SEW
CMP40M
CMP63S
CMP50S, CMP50M
Siemens
1FK7032, 1FK7034
1KF7040, 1FK7042
HT200S
HIWIN
EM1-C-M-40-2
EM1-C-M-75-2
B&R
8LSA33, 8LSA34, 8LSA35
8LSA43
Beckhoff
AM8023E, AM8023F
AM8031D, AM8031F, AM8032D, AM8032E, AM8032H, AM8531D,
AM8531F, AM8532D, AM8532E, AM8532H
AM8041D, AM8041E, AM8041H, AM8541D, AM8541E, AM8541H
Lineaire assen HM-S, lineaire tafels HT-S HMS_HTS-01-4-NL-2212-MA
Bijlage 1: Aandrijvingsaanpassing
L
[mm]
L
[mm]
Artikelnummer
F
AM
50
25,5
25-002736
60
31
25-000404
58
25
25-000403
82
31
25-000411
55
22
25-000402
70
31
25-000407
54
22
25-000401
82
31
25-000405
62
25
25-000406
55
22
25-000402
62
25
25-000406
54
22
25-000401
62
25
25-000406
55
22
25-000402
72
31
25-000408
72
27
25-000414
80
37
25-000421
86
27
25-000423
72
21
25-000413
70
27
25-000418
87
37
25-000424
82
27
25-000415
98
37
25-000425
72
21
25-000417
86
27
25-000423
72
21
25-000417
70
27
25-000418
98
37
25-000425
72
21
25-000412
86
27
25-000423
72
21
25-000417
72
27
25-000419
87
37
25-000424
72
27
25-000414
80
37
25-000421
86
27
25-000423
100
37
25-000426
72
21
25-000413
70
27
25-000418
87
37
25-000424
