3. Handle
4. Headlight (accessory)
5. Electrical enclosure
6. Lifting eye
7. Grinding head motor
8. Grinding disc motor
9. Support wheel
10. Grinding head
11. Weight lock
12. Locking pin for wheel
Product overview, left side
1. PG 690 RC, PG 830 RC: Remote control holder
2. Lock lever for handle adjustment
3. Control panel
4. Screws for handlebar adjustment
5. Battery charger connector
6. PG 690 RC, PG 830 RC: Connector for the CAN bus
cable
7. Rating plate
8. Power cord
1163 - 002 - 24.10.2019
13. Wheel
14. Weights (accessory)
15. Weight holder
16. Weight bracket
17. Grinding disc
18. Diamond tool (accessory)
19. Tool plate
20. Connection for dust extractor
21. Cover
22. Dust skirt
10
11
12
13
18
9. Suspension device for dust extractor hose and
power cord
10. Wheel motor
11. Connection for dust extractor
12. Door to electrical box
13. Support frame
14. Holes for straps
15. PG 690 RC, PG 830 RC: Remote control harness
16. PG 690 RC, PG 830 RC: Remote control
17. 1-phase charge cable
1
2
3
5
6
7
8
9
16
17
4
15
3
