CHARACTERISTICS
Components
Ref. Q.ty Product Components
1
1
Hood Body, complete with: Controls, Light,
Blower, Filters
2
1
Telescopic Chimney comprising:
2.1
1
Upper Section
2.2
1
Lower Section
9
1
Reducer Flange ø 150-120 mm
10
1
Adapting ring ø 120-125 mm
15
1
Air Outlet Connection
Ref. Q.ty Installation Components
7.2.1
2
Upper Chimney Section Fixing Brackets
11
6
Wall Plugs
12a
6
Screws 4.2 x 44,4
12c
6
Screws 2.9 x 9.5
16
2
Screws M5 x 16 (Optional)
17
1
Styling rail (Optional)
18
2
Cap (Optional)
Q.ty Documentation
1
Instruction Manual
EN
Dimensions
18
16
17
18
2
20
