8.
Place the device brackets (Figure 8, pos. 3)
over the wall bracket (Figure 8, pos. 1).
9.
Slide the device (Figure 8, pos. 2) into the
openings of the wall bracket.
10. Screw and tighten the device (Figure 9, pos.
1) with a small screw (Figure 9, pos. 3) to the
wall bracket using a Phillips screwdriver
(Figure 9, pos. 2).
Installation
WARNING
Do not put the power plug into the wall socket before the device is correctly
mounted.
Do not use an extension cable; this can cause overheating and fire. If using an
extension cable is unavoidable, make sure it is undamaged and earthed. Use
an extension cable with a minimum power of 800 Watt. Always unwind the
extension cable completely to prevent overheating.
CAUTION
Make sure that the main voltage is the same as indicated on the identification
label of the device. All electrical connections must stay dry under all
circumstances.
11. Make sure the device is correctly mounted.
12. Make sure the ON/OFF switch is in the OFF
position (Figure 10, pos. 2).
13. Place the power plug (Figure 10, pos. 1) into
an earthed wall socket that is easily
accessible. Use an earthed wall socket with a
minimum power of 800 Watt.
22
Figure 9
Figure 10
