As much as the advice does not lead to result, call the nearest brand-mark service.
Replacing the lamp
1. Disconnect the appliance.
2. Push the movable part to unhook the
lamp cover (1).
3. Remove the lamp cover (2).
4. Replace the lamp with one of the same
power and specifically designed for do-
mestic appliances only.
5. Install the lamp cover.
6. Connect the appliance.
7. Open the door. Make sure that the lamp comes on.
Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to "Installation".
3. If necessary, replace the defective door gaskets. Contact the Service Center.
TECHNICAL DATA
Dimension
Rising Time
Voltage
Frequency
The technical information are situated in the rating plate on the internal left side of the
appliance and in the energy label.
INSTALLATION
WARNING!
Read the "Safety Information" carefully for your safety and correct operation of the appli-
ance before installing the appliance.
Positioning
Install this appliance at a location where the ambient temperature corresponds to the cli-
mate class indicated on the rating plate of the appliance:
All manuals and user guides at all-guides.com
Height
Width
Depth
1
S75340KG2
1850 mm
595 mm
658 mm
18 h
230 V
50 Hz
Technical data
35
2
S75380KG2
2010 mm
595 mm
658 mm
18 h
230 V
50 Hz
