Displaying information
■
"Change"
setting.
■
"Continue"
setting and continue to the next setting.
3. "Save"
: Save all changed settings of
the menu item.
7.4
Edge mowing with a manual start
For a manual start, the setting can be made here
that the appliance begins with edge mowing.
Carrying out the edge mowing at the pro-
grammed mowing time periods: see chapter 7.3.3
"Setting the mowing times", page 48.
1.
*"Margin mowing"
2.
*"at manual start"
7.5
Setting the secondary area mowing
1.
*"Sub zone mowing"
2. Setting the mowing time periods:
■
"inactive"
area mowing is switched off.
■
"active"
mows until the rechargeable battery is
flat.
■
"Mowing time in min"
The appliance mows the secondary area
for the set time period. The following
mowing time periods can be set:
30/60/90/120/until rechargeable battery
flat.
7.6
Setting the display contrast
If the display is difficult to read, e.g. in sunlight,
the display can be improved by changing the dis-
play contrast.
1.
*"Display contrast"
2.
Increase/decrease display contrast.
7.7
Setting lock
If the setting lock is deactivated, the PIN must
only be entered when acknowledging safety-rel-
evant faults.
1.
*"Safety settings"
457290_a
: Change the selected
: Confirm the changes
: Secondary
: The appliance
2. Activating/deactivating the setting lock:
■
"Activate"
Activate the setting lock.
■
"Deactivate"
Deactivate the setting lock.
7.8
Recalibrating
If the position or length of the boundary cable has
been changed or the appliance no longer finds
the boundary cable, recalibration is necessary.
1.
"Reset calibration"
2. "Reset loop calibration data?"
3. Carrying out a calibration movement: see
chapter 5.4 "Carrying out an automatic calib-
ration movement", page 46.
7.9
Restoring factory settings
The factory settings of the appliance can be re-
stored, e.g. before selling the appliance.
1.
*"Factory reset"
message: "Factory reset completed"
8 DISPLAYING INFORMATION
The "Information" menu is used for displaying
machine data. No settings can be made in this
:
menu.
1.
Call up the main menu.
2.
*"Information"
3.
Select the menu item.
Note: The menu items are described in the
following sections.
4.
Return to the main menu.
"Blades service"
Shows in how many operating hours a blade ser-
vice is required. The counter can be reset manu-
ally. Have the blade service carried out by an AL-
KO dealer, technician or service partner.
Reset the counter for blade service:
1.
"Confirm"
"Hardware"
Shows information on the appliance, such as
type, year of manufacture, operating hours, serial
identification number, number of mowing inserts,
total mowing time, number of charging cycles,
total charging time, length of the loop of the
boundary cable.
:
:
49
