the seal stripe are located in the
middle of one side of the hob.
3. Add some mm when you cut the seal
stripe to the length.
8.5 Assembly
A
< 20 mm
A
B
12 mm
57 mm
28 mm
41 mm
38 mm
31 mm
R 5mm
490
min.
55mm
min.
500mm
min.
50mm
min. 2 mm
min. 500 mm
+1
mm
+1
270
mm
4. Push the two ends of seal stripe
together.
min.
2mm
A
B
> 20 mm
min
30 mm
A
B
12 mm
57 mm
28 mm
41 mm
38 mm
31 mm
min. 2 mm
B
min. 500 mm
min.
38 mm
min.
2 mm
