GB
3.
Instructions for assembly and installation
For the Filter System to function, it needs a skimmer (a device to clean the pool water surface). It
can be a skimmer built into the steel wall, or a raised skimmer fixed to the steel wall.
To order replacement parts, please contact your supplier indicating the type of the system/pool.
Beware!
Disconnect the plug before starting to do any work.
Before installing the filter pump unit, identify the position in which it is to be in-
stalled, as once it has been filled up with sand, the filter is hard to move due to
its weight.
Determine the place for the filter system between the skimmer and the pump inlet with af minimum
distance of 3.5 meter between the pool wall and the filter system. We recommend placing the filter
system on concrete slabs or similar. The filter system must in no way be placed in a low place or
directly on the earth, where there is a risk of flooding or overheating of the motor.
Inground or partially integrated pools
Always place the filter system under the water surface in the pool and in level with the
pool floor in the pool, so that the water can flow naturally towards the pump.
Is the system used with an inground pool, you have to place the filter system corre-
spondingly lower into a shaft/pit in the ground, so the water can flow by itself into the
pump. Be sure that the shaft/pit stays dry. There should be an outlet/drain to lead the
water out of the shaft/pit. It is also advisable to install a submergible pump with a float
switch in case of flooding. Check that the installation is in no way closed hermatically,
this could damage the pump due to the formation of water condensation.
The size of the pit must be big enough to allow maintenance or repair of the system.
Contact your supplier for necessary spare parts like the flexible tubes, the metal clips
or the filter material (not included).
MV-1088-3-2019 . © All rights reserved Swim & Fun Scandinavia ApS
Side 61
