6. Adjust the control knob to the required position. (fig.5) Never set the cartridge lever (6) to the
"UNLOCK" position during use!
FLAME GUARD
The thermocouple placed in the flame (10) controls a valve which automatically cuts off the gas intake to
the burner when this is extinguished (air draught or overflowing liquid, for example).
AFTER USE
1. Turn the control knob (8) into the "●" position.
2. Check if burner is extinguished before setting the cartridge lever (6) to the "UNLOCK" position.
3. When the appliance has cooled completely, for your own safety, remove the cartridge.
4. Fit red protective cap and always store the gas cartridge in a cool, dry, well ventilated place.
CHANGING THE CARTRIDGE
The cartridge may be removed even if it is not empty.
Once your equipment has fully cooled:
Check that the gas inlet is fully closed by turning the control knob (8) clockwise to "●" position and
that the burner (5) is extinguished.
Disconnect the cartridge by putting the cartridge lever (6) in the "UNLOCK" position.
Open the cartridge compartment cover (2) and remove the cartridge.
Butane cartridge must be changed in a safe place, e.g. in the open air or in a well-ventilated location,
preferably outside, away from any source of ignition such as naked flames, pilots, electric fires and
away from other people.
Check the seals before connecting a new gas cartridge to the appliance. (fig.6)
Put in a new cartridge by the following the instructions in paragraph "USING THE STOVE FOR THE
FIRST TIME" .
STORAGE – MAINTENANCE
When the appliance has cooled completely it should be cleaned of any residues of food or fat after
each use.
Store the appliance and the cartridge in a cool, dry and well-ventilated area, out of reach of children.
Do not modify the appliance.
WARNING
This appliance can only be used with SNN-29 butane cartridge.
Do not use an appliance which is leaking, damaged or which does not operate properly.
Always place the stove on a horizontal stable and heat resistant surface.
Do not move the appliance during use.
Never place two stoves close to each other.
Place the stove at least 20cm away from inflammable materials.
Do not use any pans that cover the cartridge compartment.
Do not use a pan smaller than 120mm or larger than 340mm in diameter for each burner. Do not use
vessels with concave or convex bottoms.
If there is a leak in the appliance (smell of gas), immediatelu turn the control knob (8) into the "●"
position. Take the appliance outside where a possible leak may be detected. If you wish to check for
leaks on the appliance, do it outside and never try to detect the leaks with a flame, but always use
soapy water!
CAUTION: Accessible parts may become very hot, keep children away from the appliance.
TROUBLE SHOOTING
No gas
Check whether the gas cartridge was inserted properly
Gas cartridge is empty (test by shaking the cartridge)
Outside temperature below 4℃, move to warmer surroundings
No ignition
Clean the burner head with a brush
In the event of any problems, please contact the dealer.
TECHNICAL CHARACTERISTICS
Model:
Type of gas:
Category direct pressure:
Nominal heat input:
Gas consumption:
Orifice diameter:
Outlet pressure of the valve:
Switch pressure range of overpressure shut-off device
st
1 stage safety device:
nd
2 stage safety device:
Importer:
IMPORTER：Isabella A/S
Isabellahøj 3 Denmark-7100 Vejle
900060508
Butane
Vapour pressure butane
2.2 kW x 2
160 g/h x 2
0.6 mm
7.65 kPa
4.0 bar – 6.0 bar
4.0 bar – 6.0 bar
2806/22
