Original instructions for use
ORIGINAL INSTRUCTIONS FOR USE
Contents
About this handbook........................................ 11
Product description.......................................... 11
Scope of supply............................................... 12
Safety instructions............................................12
Assembly.......................................................... 12
Startup.............................................................. 13
Maintenance and care..................................... 13
Storage............................................................. 13
Disposal............................................................13
Help in case of malfunctions............................14
Warranty........................................................... 15
EU declaration of conformity............................15
ABOUT THIS HANDBOOK
Read this documentation before starting up
the machine. This is a precondition for safe
working and flawless operation.
Observe the safety warnings in this docu-
mentation and on the product.
This documentation is a permanent integral
part of the product described and must be
passed on to the new owner if the product is
sold.
Explanation of symbols
CAUTION!
Following these safety warnings care-
fully can prevent personal injury and/or
material damage.
Special instructions for greater ease of
ADVICE
understanding and improved handling.
PRODUCT DESCRIPTION
This documentation describes various different
models of immersion pumps. Identify your model
using the identification plate.
Product overview
1 Connection cable with mains plug
2 Carrying handle
467 771_a
3 Float switch cable
4 Pump housing
5 Float switch
6 Suction slots
7 Connection elbow
8 Combination nipple
9 Venting (only Drain 10000/15000 INOX)
Function Drain 10000 / 12000
The immersion pump draws the conveying me-
dium through the suction slots directly and feeds
it to the pump outlet at the combination nipple. It
is switched on and off using a float switch.
Function Drain 10000 INOX / 15000 INOX
The immersion pump draws the conveying me-
dium through the suction slots directly and feeds it
to the pump outlet. It is switched on and off using
a float switch. In order to operate properly, the im-
mersion pump must be vented at the venting fa-
cility.
Inox stainless steel
Units marked with the designation "INOX" are
supplied in stainless steel. The structure and func-
tion are unaffected by this.
Designated use
The immersion pump is designed for private use
in the house and garden. It must only be operated
within the framework of the deployment limitations
in accordance with the technical data.
The immersion pump is suitable for:
Water removal in the event of a flood
Re-pumping and pumping out from vessels
(e.g. swimming pools)
Water removal from streams and shafts
Water removal from drains and trickle shafts.
The immersion pump is only suitable for convey-
ing the following fluids:
Clear water, rainwater
Chlorine-containing water (e.g. swimming
pools)
Waste water
Dirty water having a max. suspended matter
proportion of 5 % and a grain size of max. 30
mm diameter.
11
