manual - OBlOnG
Manual
cOntent
1. Introduction
2. assembly
2 .1 Earth works
3. Options
3 .3 Safety tarpaulin
3 .4 Technical housing
3 .5 Felt
3 .10 Slide lock cover roller
6 .3 Filter / pump
6 .4 Summer, winter or
safety cover
44
1. Introduction
Congratulations on purchasing your
Gardipool swimming pool . Your pool is
manufactured from quality North-Euro-
pean pressure impregnated pinewood .
This treatment offers protection against
rotting and keeps the wood mould-free .
The top border is either in North-Euro-
pean pine or in exotic hardwood, which is
by nature very resistant .
Enclosed, you will find the instructions
for the do-it-yourself assembly of your
Gardipool .
It is advisable that you read the complete
instructions before you start with the
assembly of the pool .
Always follow all safety regulations .
Should you encounter any problems du-
ring the construction, please contact your
Gardipool sales representative, who will
assist you with help and advice .
The assembly instructions are applicable
to all models, unless stated otherwise .
Without supervision,
your child is in danger .
2. assembly
2.1 earth works (1, 2)
The pool should preferably be positioned
in a sunny place, away from any trees
whose leaves could fall into the pool .
It is extremely important that your pool
be assembled on a stable foundation .
This should be a 15 cm (6 inch) thick flat
concrete slab . Apply a layer of plastic foil
underneath the concrete slab to obtain
an optimal drying .
In (half) sunken pools, allow an additional
border of ± 50 cm (20 in) around the
pool . In this case, you must cover the
underground wooden structure with a
protective felt layer to ensure that the
structure never touches the ground
directly . This forms the division between
the structure and the stabilized sand
with which you filled the gap after the
assembly of the pool, to ensure ad-
equate drainage of the ground water and
rainwater . You must also ensure that the
ground and rain water around the pool
is discharged effectively by means of an
adapted drainage system .
Make sure that the ground or water
never touches the wooden structure
directly .
Provide an adapted felt layer around the
pool as protection . The finishing around
the pool can be chosen according to your
personal taste: wooden terrace, planks,
paving stones, tiles, or lawn (only a top
layer of 10 cm (4 inches)) .
Oblong (3)
Metal support profile for OBLONG .
When pouring the foundation slab,
you must provide 1 or 2 openings for
OBLONG 6 .2 and 2 or 3 openings for
OBLONG 8 .1 in which the galvanised
profiles will be placed . Refer to the
drawing for the correct position .
The openings are at least 30 cm (12 in)
wide and 20 cm (8 in) high . The profiles
provide adequate strength to the exten-
ded wooden structure . Attach the profiles
with bolts and nuts . Check whether the
horizontal profiles are perfectly level, and
the vertical profiles are at right angles .
Pour some stabilised sand in the opening
and place profile 160 underneath the pool
and 120 vertically next to the pool .
