1 – SCOPE OF APPLICATION
2 – TECHNICAL SPECIFICATIONS
3 – COMMISSIONING
4 – USE
5 – CLEANING / MAINTENANCE
6 – USABLE NOZZLES
7 – FOR YOUR SAFETY
8 – PRECAUTIONS FOR USE /
CHECKS TO BE PERFORMED
9 – MALFUNCTIONS
10 – SYMBOLS USED
11 – EXPLODED VIEW / SPARE PARTS
Please read the manual before first
use.
1 - SCOPE OF APPLICATION
This machine is specially designed for the
application of GARDEN PLANT PROTECTION
products (fungicides, herbicides, insecticides).
This sprayer IS NOT SUITABLE for the
application of products for disinfecting livestock
facilities and of all "Industrial" products (laundry
products (alkaline), caustic soda, bleach, etc.).
For any other application, you MUST consult the
MANUFACTURER.
This sprayer must be used only with crop
protection products approved by local/national
regulatory
authorities
products intended for backpack sprayers. This
machine must not in any circumstance be used
to spray flammable or potentially flammable
products.
2 - TECHNICAL SPECIFICATIONS
Backpack
sprayer,
with
adjustable
PRESSURE,
RECHARGEABLE battery:
- Empty weight: 6.2 kg. (24.2 kg filled with water)
- Blown polyethylene tank.
- Visible liquid level.
- Graduated external gauge.
- Total capacity: 18 litres.
All manuals and user guides at all-guides.com
for
crop
protection
CONSTANT
and
operating
on
a
ENGLISH
- Adjustable, padded carrying straps.
- Flexible back pad and adjustable belly strap.
- Ergonomic carrying frame, with built-in carrying
handle.
- Electric double diaphragm pump.
- Operating pressure of 1, 1.5 and 3 bar
- Electronic control for adjusting pressure
- Handle with resistant seal (material: FKM).
- Composite telescopic lance equipped with a
nozzle holder; supplied with a complete set of
nozzles (swirl, flat fan and anvil nozzles).
- Tank filter
- 12 Volt lithium-ion battery.
- Dedicated 12 volt battery charger.
- This machine must not be used at a
temperature lower than 5° C and higher than
40° C.

3 - COMMISSIONING

1.
Screw the telescopic lance onto the lance
handle. Check that the seal is present (Fig.
1).
2.
Remove the battery from the sprayer.
3.
Disconnect the battery if necessary.
4.
Connect the charger to your battery via the
charging socket, and then connect the
charger to the mains socket. (Fig. 8).
Use only the charger supplied with the
machine to charge the battery
a.
The charger's RED indicator
turns on, indicating that the battery is being
charged. (Fig. 3).
b.
When the charging is complete, the
RED indicator turns green, indicating that
your machine is ready for use (or storage).
5.
Unfold the telescopic lance
6.
Place the sprayer on your back and adjust
the harness as shown in the 4 photos
(Fig. Safety harness)
*The telescopic lance is recommended for
spraying at heights and the fibreglass lance for
spraying at ground level, especially with spray
booms.
