D i r ec tion but t ons
The centre of the selected oscillation angle can be set with the buttons
As long as you press the buttons
the right. As soon as you release the button, the fan oscillates within the selected
angle with the centre of the angle located where the direction button was released.
Note: The centre of the oscillation angle can be set by hand to an angle
between 0° and 360°.
The vertical inclination can be set by hand to the following angles:
-8°, 0°, 10°, 20°, 30°, 40°, 50°, 60°, 70°, 80°, 90°.
If the angle is set to 90°, the fan head is completely horizontal, the air circulates
upward without generating unpleasant, direct air draughts.
Horizontal orientation:
electric or manual setting
possible
O sc i ll at ion but t on
Your fan can permanently swivel from the left to the right. At what angle this should
happen has to be previously set by you.
The automatic, horizontal oscillation can be set to the following angles with the
oscillation button
: 0 (no lines on the display, the oscillation stops) – 60° – 90° –
180° – 360° – 0 (oscillation stops). By each press of the
to the next angle. The setting can be read off the display by the beam shaped lines.
8
Oscillation at a 60° angle
Oscillation at a 180° angle
8
or
, the fan head moves either to the left or
Vertical orientation:
only manual setting
button, the setting jumps
8
Oscillation at a 90° angle
360° rotation
8
.
73
