sAFeTY ADVIce
• The mounting must only be done by experts.
• Please read through the mounting instructions carefully
before mounting in the bathroom.
• Warning: defective mounting is dangerous!
• Check whether the wall is suitable for the mounting and
that the fasteners are strong enough for the forces involved.
• The enclosed fastening material is only suitable for solid walls
of sufficient load-bearing strength.
• If the nature of the wall is different (e.g. plasterboard or
lightweight walls), a different fastening which is suitable for
the load should be chosen by the customer.
•
Electrical installations should only be carried out by a
specialist electrician DIN VDe 0100-701 (VDe 0100-701):2008-10.
• electrified, mirrored cabinets and flat mirrors must be located
at a minimum distance of 600 mm away from the bath or
shower.
• The safety regulations and standards of the particular coun-
tries must be observed.
IMPORTANT INFORMATION
• Inspect the packaging for external damage when it is delivered.
• Please check the number of bathroom cabinets supplied and
the associated sets of ironmongery (screws, cover caps,
handles, etc.) against the delivery note or the article's label
on the packaging.
• Caution: only remove the protective caps on the mirrored
cabinet's doors after mounting the doors, in order to avoid
damaging edges of the mirrors.
• Use suitable spacers or distance blocks to even out the exist-
ing differences in level caused by coverings applied to the
walls, e.g., partial tiling.
• reinforce any walls of insufficient load-bearing strength.
• The drilled dimensions are measured from the FFL according
to the dimensioned layout.
• Always fasten the hanging bar to the wall with 2 screws!
• Fasten the cabinets with the suspension rails:
- Tall cabinets (600 mm width)
- Highboard with drawer
- Vanity unit with drawer
- Washstand vanity unitvv (700 mm/900 mm width)
- Washstand floor cupboard for a double washstand (1400
mm width)
• The horizontal spacing between the cabinets can be chosen
freely.
• Do not tighten water tap and sink pop-up too firmly.
• Bonded joint between the washstand and the shelf is formed
with silicone (transparent and free of solvents)
• Hanger assembly of the mirror cabinets (1400 mm width)
with four screw hooks
TOOLS
• Drill and battery-operated screwdriver
• Stone drill bit of 8 mm dia, Wood drill bit of 4 mm
• Folding metre rule and measuring tape
• Spirit level
• Screwdriver with a 3.5 mm tip for Phillips screws
• 10 wide open-jawed spanner
• Screw clamps
• Pencil
• silicone sealant (transparent and solvent-free)
Vuelta
MAINTENANCE INSTRUCTIONS
• Caution: do not use any chemicals, aggressive detergent
paste or scouring powder.
• The best way of cleaning the cabinet is to use a damp cloth
with some mild washing-up liquid.
• Take care that no residue from droplets remains on the lower
edge of bathroom cabinets.
• Polish the mirror with a damp cloth or chamois leather.
• The washbasin can be easily cleaned with any of the usual,
non-abrasive cleaning agents.
• Ventilate regularly in order to prevent the mould from forming.
KEEP THE INSTRUCTIONS IN A SAFE PLACE
i
Caution: keep the instructions safely because they contain
information about installing and operating the products.
MOUNTING SEQUENCE
i
For the figures, see the attachment
1. Dismantle the doors (Fig. A)
2. Dismantle the drawers
· standard technology (Fig. A1)
· comfort technology (Fig. A2)
3. Mount the mirror grip (Fig. B)
4. Mount the lamps (Fig. C/C1/C2/C3)
The mains wire should not be live!
Do not overtighten the acryl panel light!
5. Screw washbasin vanity units (Fig. D/D1)
Warning: Hold up mounting wood when drilling
through!
6. Hang up the furniture
(Fig.
·
Mirrored cabinet or flat mirror (centre of the mirrored
cabinet = centre of the water supply connection)
· Washstand vanity unit
· tall cabinets, upper cabinets, centre cabinets
· Washstand
(Middle washstand = Middle water connection)
· Highboard
· Protoboard
7. Align furniture (Fig. F/F1/F2)
8. Mount the washstand with the LED (Fig. G)
The mains wire should not be live!
9. Mount the washstand (Fig. G1/G2)
10. Install the tap (Fig. H)
· Warning: Use the enclosed rubber seal.
· Do not overtighten the tap!
11. Screw on the shelf (Fig. I)
· Warning: Do not drill through the shelf!
· use the enclosed screws.
12. Mount the protoboard (Fig.
13. Mount the doors (Fig. K)
14. Mount the drawers
· standard technology (Fig. L)
· comfort technology (Fig. L1)
15. Aligning the doors (Fig. M/M1/M2)
16. Align the drawers
· standard technology (Fig. M3)
· comfort technology (Fig. M4/M5/M6)
17. Adjusting the folding hinge (Fig. N)
E/E1/E2)
J)
