TECHNICAL SPECIFICATIONS
pH/RX Inputs
Measure Ranges
Precision
Precision Repeatability
Configuration
LEV Inputs
FLOW Input
Serial Port
Relay Output
Display
Dosing Pumps
Power Supply
Protection Fuse
Environment
Casing
Installation
Protection Rate
Dimensions
Weight
Available on BNC connectors, input impedance > 10^12 Ω.
0.00 to 14.00 pH, 0 to 1000 mV (redox).
Deviations less than 1% of the full scale
(when properly calibrated).
Better than 0.2% of the full scale.
Two configuration level (standard and advanced).
2 independent inputs for level sensors, available
on connectors, SPDT contact 5 V / 5 mA.
1 input that can be used for connecting both the filter pump
contactor or the flow sensor (SPDT contact 5 V / 5 mA).
RS232, available on external connector (optional).
NO/NC configurable contact for alerting (optional).
Large alphanumeric, double row (x 16 characters) LCD, with backlight
Flow rate: 4 l/h @ 1 bar.
Materials: fiberglass reinforced PP pump head and fittings,
Santoprene (silicone upon request internal tube, PBT roller holder,
Delrin (self- lubricant) rollers. Max suction height: 1.5 m.
Standard 230 V~, 50 Hz (other options upon request) ; 20W.
F1A 5x20 (230V ~).
Storage temperature -20 tot +60° C.
Working temperature -10 tot +40° C.
RH
max. 90% non condensing.
Self-extinguish plastic material with polyester front panel.
Wall installation with supplied screws and stoppers.
IP65.
290 x 280 x 175 mm.
Approx. 4 kg.
180
250
280
UV-C and Pool equipment
BL530 PH/RX DOSAGE SYSTEM |
EN
5
