ENGLISH
MAINTENANCE
Make sure the area below the installation place is free from unwanted persons during servicing.
Switch off the unit, unplug the mains cable and wait until the unit has been cooled down.
During inspection the following points should be checked:
All screws used for installing the device and any of its parts should be tightly fastened and may not be
corroded.
Housings, fixations and installations spots (ceiling, truss, suspensions) should be totally free from any
deformation.
When an optical lens is visibly damaged due to cracks or deep scratches, it must be replaced.
The mains cables must be in impeccable condition and should be replaced immediately when even a
small problem is detected.
In order to protect the device from overheat the cooling fans (if any) and ventilation openings should be
cleaned monthly.
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,
smoky or particularly dirty surroundings can cause greater accumulation of dirt on the unit's optics.
Clean with a soft cloth using normal glass cleaning products.
Always dry the parts carefully.
Attention: We strongly recommend internal cleaning to be carried out by qualified technician!
SPECIFICATIONS
Mains Input:
Power consumption:
Fuse:
DMX connections:
DMX channels used:
Lamp:
LED Refresh rate:
Beam Angle:
Size:
Weight:
You can download the latest version of this user manual on our website: www.briteq-lighting.com
BRITEQ
®
AC 110V - 240V, 50/60Hz
125 Watt max.
250V T2A (20mm glass)
3pin + 5pin XLR male / female
1+2 channels
100W warm white COB 3200K
CRI = 85
1200 Hz
10° – 50°
see drawing
6,5 kg
The information might be modified without prior notice
8/35
OPERATION MANUAL
BT-THEATRE 100EC
