3
With the optional build-in set:
This requires the optional EMC-iSet.
This product may be installed in zone 3 only.
Refer to the drawing to the right to determine
suitable locations.
Build the conduit box into the wall at the spot you
wish to place the wall mount. Pull
two electrical wires (230V) through the conduit
pipe and leave around 10 cm visible in the
conduit box. Connect the build-in adapter and
place it in the conduit box. Insert the Micro-USB
in the back of the wall mount. Place the wall
mount exactly over the conduit box.
Make sure the surface where you will place the
wall mount is clean and dry. Remove the cover
layer of the tape strip on the back of the wall
mount.
Place*
wall for 5 seconds. The tape will ensure a
waterproof closure for the conduit box.
The wall mount is placed and ready for use.
Final result:
The final result is a wall mount / charger that is
ready to be used.
*
First check if the wall mount functions in charging the controller before you place it on
the wall, the wall mount cannot be easily removed once attached.
the wall mount and press it to the
24
