Extern display PR 5110/01
Configuratie
PR 5900
[Bediening] - [Systeeminrichting] - [Aangesloten apparaten]
- [Afstandsdisplay] - [Interface] - [Intern RS‑485]
4.3.2
RS-232-interface
NL-34
In het externe display zit standaard een RS-232-interface ingebouwd.
RS-485
Com 1
RS-232
1
9
Externe aansluiting
Schakelkastbehuizing
Technische gegevens
Benaming
Aantal kanalen
Type
Overdrachtssnelheid [bit/s]
Pariteit
Databits
Ingangssignaalniveau
PR 5110
[
[
[
[
[
RS-232
Com 2
LOCK supply voltage
1
2
3
4
5
9‑polige D‑Sub bus (male)
5‑polige insteekklem
Gegevens
1
RS-232, full-duplex
2.400...19.200
even
7
Logisch 1 (high) -3...-15 V
Logisch 0 (low) +3...+15 V
4 Apparaatinstallatie
] - [oP 10] - [LInE] - [rS485]
] - [oP 12] - [tokEn] - [oFF]
] - [oP 13] - [SEndModE] - [SEnd]
] - [oP 14] - [WEIght] - [FolloW]
] - [oP 15] - [WPkEy] - [SElEct]
