RS 145 E
REPLACEMENT OF THE WICK
O
ENSURE THAT THE HEATER IS OFF AND COMPLETELY
COOL BEFORE STARTING TO REPLACE THE WICK.
1
Open the lid and remove the removable tank.
2 2
2
Remove the batteries from the battery holder.
3
Open the front grill. Remove the combustion chamber
from the heater. Close the grill.
4
Pull the knurled wick adjustment knob off the heater.
4 4
5
Unscrew the three cabinet screws on the back and sides
of the heater. Pull the cabinet forward slightly, and then
remove it from the base plate.
6
Unscrew the four wing nuts from the wick holder.
5 5 b b
7
Lift up the wick holder and the wick mechanism.
8
Squeeze the wick to loosen the three wick pins and
remove the wick from the wick holder. Ensure that you
are wearing gloves and that you have a container in
which to put the old wick.
7 7
9
Put the wick holder back into position in such a way
that the holes in the wick holder are directly above the
inner sides of the recesses in the burner. Ensure that the
holes are facing down.
10
Fold a new wick and place it in the wick holder. Push
the three wick pins into the wick holder holes, and
9 9
therefore also into the recesses inside the burner. Push
the wick with the wick holder up into the recesses as far
as possible. Push the pins firmly until you hear a clicking
sound. Ensure that the wick holder does not bend!
1 1 0 0 b b
