Button
Function
<DOWN>
scrolls through the menu options in descending order
<LEFT>
goes to lower level of menu
<RIGHT>
goes to higher level of menu
<ENTER>
used to select and store the current menu or option within the menu
The control panel display shows the menu items you select from the menu map. When a menu
function is selected, the display will show immediately the first available option for the selected menu
function. To select a menu item, press <ENTER>.
Use the <UP> and <DOWN> buttons to navigate the menu map and menu options. Press <ENTER>
to access the menu function currently displayed or to enable a menu option. To return to the
previous option or menu without changing the value, press the <ENTER> button.
To change a setting
1.
Press <ENTER> to enter the menu.
2.
Press <UP> or <DOWN> to change the setting.
3.
Press <ENTER> to confirm (or press <RIGHT> to cancel).
The menu contains the following items:
Menu
Submenu
Connect
DMX Address
XXX
Max
80~139°C, 90°C /176~282°F, 194°F
Light
Temperature
Lamp Adjust
PAN...
Informat
ion
Time Info.
Current
Fixture Life XXXX(Hours)
Temperature
Near Lamp Temp (depends on fixture)
Fans Speed
Near Lamp Fan (depends on fixture)
Channel
Value
PAN...
Error
Message
Pan,Tilt...
Fixture
Model
xxxxxxxxxxxx
Software Ver
1U01 V1.0.00
2U01 V1.0.00
Set
Reset
All
Pan&Tilt
Others
Movement
Pan Reverse
Tilt Reverse
Pan Degree
Encoders
Pan/Tilt Mode
UI Set
Mic Sens.
No Signal
Temperature. C/F
Fans Mode
Hibernation
Backlight
Flip Display
Display Bright
Brand Show
Key Lock
Users
User Mode
V. 01 – 30/04/2013
All manuals and user guides at all-guides.com
LX200Z
Options
XXXX(Hours)
ON/OFF
ON/OFF
630/540
ON/OFF
Stand/Smooth
0~99%,60%
Close/Hold/Auto/Music
Fahrenheit /Celsius
Auto Speed /High Speed
OFF, 01M~99M，15M
02~60m 02m
ON/OFF
00~31 10
ON/OFF
ON/OFF
Standard
Extended 1
Extended 2
6
Function
Sets DMX address
Turns of the lamp if temperature
exceeded for 5 minutes
Adjust value of each channel
Fixture boot time
Fixture total run time
Temperature sensors
Fan speed sensors
Display value of channel
Error channels
Displays fixture brand and model
Version of each ic
Reset all
Reset pan&tilt
Reset others
Pan reverse
Tilt reverse
Choose pan degree
Turns encoder wheel on/off
Choose pan/tilt mode
Sets the microphone sensitivity
Sets the mode when there is no
signal
Sets the temperature unit at
°C/°F
Sets the fan mode
Sleeping mode
Sets the backlight time
Reverses the display by 180°
Sets display brightness
Show or hide brand
Sets key lock on/off
Standard mode (16bit)
Extended mode 1
Extended mode 2
©Velleman nv
