HALOTRONIC
Electronic trailing edge dimmer for incandescent lamps,
electronic transformers and line voltage LED lamps
V
230V / 50Hz
AC
V
.. V
/ f
207 .. 254 V / 50Hz
MIN
MAX
2)
DC Operation
NOT ALLOWED!
P
≤ 4 W
V MAX
P
≤ 0.5 W
V Standby
t
.. t
0 .. 50°C
MIN
MAX
3)
Control interface
DALI; Touch DIM
4)
Dimmer type
trailing edge; phasecut
5)
Dimming range
0.1 .. 100 %*
* Depending on the light source. For details see www.osram.com
®
HTi DALI 315 DIM
2)
t
a
P
MIN
P
MAX
B 10A
4)
B 16A
6)
1)
HAL
50°C
40°C
≥ 20 VA
≥ 20 VA
≤ 315 VA
≤ 420 VA
6x
5x
10x
7x
LED
50°C
40°C
≥ 3 VA
≥ 3 VA
≤ 200 VA
≤ 200 VA
6x
6x
10x
10x
