Parts & features remote control
Power ON/OFF button (Standby mode)
A
MUTE button, mute or resume the sound
B
MODE buttons, select the input source.
C
VOL+/VOL- buttons, increase/decrease the volume level.
D
&
buttons, skip to previous/next track in BT mode.
E
/PAIR button, play/pause playback in BT mode &
F
press and hold to activate the pairing function in BT mode or disconnect the existing
paired BT device.
EQ button, equalizer, select a preset sound effect
G
Initial setup remote control
The provided remote control allows the device to be
operated from a distance.
Even if the remote control is operated within the
effective range (<6m), remote control operation may be
impossible if there are obstacles between the device
and the remote control.
The device may operate incorrectly if the remote
control is operated near other products that generate
infrared rays, or if other remote control devices using
infra-red rays are used near the device. Conversely,
the other products may operate incorrectly.
First-time use:
The remote control has a pre-installed lithium CR2025
battery. Remove the protective tab to activate the
remote control battery.
Inserting the remote control battery:
1) Push the security lock
2) Pull out the battery tray and remove the old battery.
3) Place a new CR2025 battery into the battery tray
with correct polarity (+/-) as indicated.
4) Replace battery tray in the slot.
Placement / mounting of the device
The device can be placed on a table or TV stand, or
mounted on a wall.
A. If your TV is placed on a table or TV stand, you
can place the device on it directly in front of the TV,
cantered with the TV screen.
B. If your TV is attached to the wall, you can mount the
device centred on the wall directly below the TV screen
All manuals and user guides at all-guides.com
A
C
D
2
1
4
B
E
F
G
3
EN 05
