WARNING
1. Ensure good ventilation during charging. Stay away from fire or explosive materials!
2. High voltage in the charger! DO NOT disassemble or replace parts of the charger.
3. DO NOT connect the charger to the power outlet for a long time. Unplug from the power outlet when not
charging. DO NOT use the charger to charge multiple vehicles.
4. The charger should be handled with care. Keep away from outdoor elements such as rain and heat.
5. For more information about the repair and maintenance, please visit http://nl-nl.segway.com/after-sales.
NOTICE: INSURANCE
YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS INVOLVING THE USE
OF THIS PRODUCT. TO DETERMINE IF COVERAGE IS PROVIDED, PLEASE CONTACT YOUR INSURANCE
COMPANY OR AGENT.
19
9. Specifications
Items
Vehicle dimensions: length × width × height
Net weight (battery included)
Max. payload
Wheelbase
Ground clearance
Max. speed
Electric range (WMTC Stage
3)*
Vehicle
parameters
Typical
range*
Electric energy consumption
Max. slope
Operating temperature
Storage temperature
Charging temperature
IP ratings
Battery type
Nominal voltage
Battery pack
Rated capacity
Rated energy
Charging time
Motor type
Motor
Rated voltage
Input voltage
Charger
Output voltage
Output current
Tyre
Shock absorption
Others
Front brake
Rear brake
Handle grip material
*WMTC criteria: 75kg load ±5kg, 1.75m ±0.05m max wind speed of 3m/s with a minimum air temperature of 5ºC and a maximum of 35ºC.
*Typical range: The accumulated range of the vehicle (25 km/h or 45 km/h version) tested at their respective maximum speed with 165 lbs
(75 kg), 77 °F (25 °C), wind speed ≤ 3m/s on a paved road until no more power remains.
*Some of the factors that affect range include: rider weight, number of starts and stops, ambient temperature, etc.
e.g. (B110S) maximum achievable range of about 105 km at a constant speed of 20 km/h with 75±5 kg load in about 25 °C temperature.
B110S
66.3 × 27.2 × 43.1 in (1685 × 691 × 1095 mm)
123.5 lbs (56 kg)
Approx. 220 lbs (100 kg)
46.7 in (1187 mm)
9.84 in (250 mm)
25 km/h
45 km/h
64 km
56 km
90 km
72 km
23 Wh/km
26 Wh/km
Approx. 15°
0–133°F (-18–45°C)
-4–122°F (-20–50°C); 50–86°F (10–30°C) recommended
36–104°F (2–40°C); 50–95°F (10–35°C) recommended
IPX5
Lithium-ion battery
48 V
30 Ah
1440 Wh
About 4 hours
Permanent magnet motor
48 V
100–240 V AC
52.5 V DC
8 A
Tubeless tyre Front: 12 × MT1.50 Rear: 10 × MT1.85
Centered twin-tube dampers
Hydraulic disc brake 180mm-3.5mm
Hydraulic Disc Brake 155mm-3.5mm
PVC
20
